Exterior Wall Lighting
Sculpted modular wall lighting with precise up-and-down illumination
This outdoor wall light uses a black aluminium housing and high-transparency optical lenses to create a controlled architectural lighting effect across exterior walls. Each module has a softly curved face that gives the fixture a subtle wave-like profile, with multiple modules combining into increasingly wider linear compositions.
Four configurations are available: 2-Light at W 2.6″ × H 4.3″ (W 6.6 × H 10.9 cm), 4-Light at W 4.7″ × H 3.9″ (W 11.9 × H 9.9 cm), 6-Light at W 6.9″ × H 3.9″ (W 17.5 × H 9.9 cm), and 8-Light at W 9.1″ × H 3.9″ (W 23.1 × H 9.9 cm). The hardwired fixture operates at 85–265V and uses warm white 3000K LED illumination.
01
Four Configurations
Choose from 2-Light, 4-Light, 6-Light and 8-Light formats to suit different wall proportions.
02
Up & Down Light
Directed illumination creates defined light above and below the fixture.
03
Optical Lens
High-transparency lenses help shape the LED output into a clean architectural effect.
04
IP65 Rated
IP65-rated protection supports installation across suitable outdoor environments.
Design & Illumination
A repeating curved profile designed to shape the wall with light
Modular sculptural form
The fixture is built from repeating curved modules, creating a subtle scalloped rhythm across the wall. The 2-Light version remains compact and vertically proportioned, while the wider configurations extend the same geometry horizontally for greater architectural presence.
Controlled optical distribution
High-transparency optical lenses direct the LED output above and below the housing, allowing the light pattern to become part of the surrounding architecture rather than exposing the light source directly.
Dimensions
Four configurations from 2.6″ to 9.1″ wide
The compact 2-Light format measures 2.6″ (6.6 cm) wide and 4.3″ (10.9 cm) high. The 4-Light, 6-Light and 8-Light configurations share a 3.9″ (9.9 cm) height and increase progressively in width from 4.7″ (11.9 cm) to 9.1″ (23.1 cm).
| Configuration |
Imperial |
Metric |
| 2-Light |
W 2.6″ × H 4.3″ |
W 6.6 × H 10.9 cm |
| 4-Light |
W 4.7″ × H 3.9″ |
W 11.9 × H 9.9 cm |
| 6-Light |
W 6.9″ × H 3.9″ |
W 17.5 × H 9.9 cm |
| 8-Light |
W 9.1″ × H 3.9″ |
W 23.1 × H 9.9 cm |
Technical Details
Product specifications
Product Type
Up & Down Wall Light
Power Supply
Hardwired
Voltage
85–265V
Power Options
2W / 4W / 6W / 8W
Material
Aluminium and Optical Lens
Finish
Black
Light Source
LED
Colour Temperature
Warm White 3000K
Configuration Options
2-Light / 4-Light / 6-Light / 8-Light
Control Type
Wall Switch
Mounting Type
Wall-Mounted
IP Rating
IP65
Configuration Options
Scale the fixture from a compact accent to a wider linear composition
2-Light
2.6″ Wide × 4.3″ High
W 6.6 × H 10.9 cm. The most compact option, suited to focused architectural accents and narrower wall sections.
4-Light
4.7″ Wide × 3.9″ High
W 11.9 × H 9.9 cm. A wider two-module format that extends the sculpted profile horizontally.
6-Light
6.9″ Wide × 3.9″ High
W 17.5 × H 9.9 cm. A three-module configuration with greater visual presence across broader exterior walls.
8-Light
9.1″ Wide × 3.9″ High
W 23.1 × H 9.9 cm. The widest configuration for a more pronounced linear architectural feature.
Lighting Character
Warm directional light with a defined architectural effect
The 3000K LED illumination is directed through the optical lenses to create controlled light above and below the fixture, adding depth to exterior walls and highlighting surface texture.
Wider configurations extend the repeated lighting rhythm horizontally, allowing the fixture to move from a compact wall accent to a stronger linear element across larger façades.
Placement
Designed for façades, porches, patios and exterior passageways
Exterior Walls
The up-and-down light pattern adds depth to flat wall surfaces and emphasises architectural texture after dark.
Porches & Patios
Compact depth and multiple widths make the fixture suited to exterior living areas where controlled wall lighting is preferred.
Corridors & Passageways
Four configuration widths allow the fixture to be scaled according to narrower circulation areas or broader wall sections.
Outdoor Performance
IP65-rated protection for exterior wall applications
The fixture carries an IP65 rating for outdoor protection. Its aluminium housing and optical lens construction are intended for suitable exterior installations where resistance to rain and dust is required.
Installation
Hardwired wall-mounted installation
The fixture is designed for fixed wall mounting, operates at 85–265V and is controlled through a wall switch.
Professional installation recommended. Electrical installation should be completed by a suitably qualified electrician and in accordance with applicable local electrical requirements.
Care
Simple care for aluminium and optical surfaces
Switch off power before cleaning. Wipe the fixture using a soft, dry or lightly dampened cloth and avoid abrasive pads or harsh chemical cleaners.
Dimension Reference
2-Light, 4-Light, 6-Light and 8-Light configurations
